PRODUCTS

BUCs

    Ka Band

    Model
    ACTX-Ka Low Power Series GaN
    Frequency
    27.5 - 31.0 GHz
    Power (Psat)
    4 W
    Datasheet
    Model
    ACTX-Ka Low Power Series GaN
    Frequency
    27.5 - 31.0 GHz
    Power (Psat)
    8 W
    Datasheet
    Model
    ACTX-Ka Medium Power Series GaN
    Frequency
    27.5 - 31.0 GHz
    Power (Psat)
    20 W
    Datasheet
    Model
    ACTX-Ka Medium Power Series GaN
    Frequency
    27.5 - 31.0 GHz
    Power (Psat)
    40 W
    Datasheet
    Model
    ACTX-Ka Medium Power GaN Series (Compact)
    Frequency
    27.5 - 31.0 GHz
    Power (Psat)
    40 W
    Datasheet
    Model
    ACTX-Ka High Power Series GaN
    Frequency
    27.5 - 31.0 GHz
    Power (Psat)
    100 W
    Datasheet

    X Band

    Model
    ACMB-X Low Power Series
    Frequency
    7.9 - 8.4 GHz
    Power (P1dB)
    20 W
    Datasheet
    Model
    ACMB-X Low Power Series
    Frequency
    7.9 - 8.4 GHz
    Power (P1dB)
    40 W
    Datasheet
    Model
    ACMB-X Medium Power Series
    Frequency
    7.9 - 8.4 GHz
    Power (P1dB)
    80 W, 100 W
    Datasheet
    Model
    ACTX-X Medium Power GaN Series
    Frequency
    7.9 - 8.4 GHz
    Power (P1dB)
    100 W
    Datasheet
    Model
    ACTX-X High Power Series
    Frequency
    7.9 - 8.4 GHz
    Power (P1dB)
    150 W
    Datasheet
    Model
    ACTX-X High Power Series
    Frequency
    7.9 - 8.4 GHz
    Power (P1dB)
    200 W
    Datasheet

    LNBs

      Ka Band

      Model
      ACLNBS-Ka Standard Series
      Frequency
      19.2 - 22.2 GHz
      Noise Figure
      1.5 dB
      Datasheet
      Model
      ACLNBP-Ka Premium Series
      Frequency
      20.2 - 21.2 GHz
      Noise Figure
      1.5 dB
      Datasheet
      Model
      ACLNBD-Ka Dual Band Series
      Frequency
      19.2 - 21.2 GHz
      Noise Figure
      1.6 dB
      Datasheet
      Model
      ACLNBDI-Ka Dual Band Series Simultaneous Ouptuts Ref. Int.
      Frequency
      19.2 - 21.2 GHz
      Noise Figure
      1.6 dB
      Datasheet
      Model
      ACLNBDI-Ka Dual Band Series Simultaneous Ouptuts Ref. Int.
      Frequency
      17.7 - 20.2 GHz
      Noise Figure
      1.6 dB
      Datasheet
      Model
      ACLNBW-Ka Wideband Series
      Frequency
      17.7 - 21.2 GHz
      Noise Figure
      1.8 dB
      Datasheet
      Model
      ACLNBW-Ka Wideband Series Simultaneous Outputs
      Frequency
      17.7 - 21.2 GHz
      Noise Figure
      1.8 dB
      Datasheet
      Model
      ACLNBDI-Ka Dual Band Series Simultaneous Ouptuts Ref. Int. & Input sample port
      Frequency
      17.7 - 20.2 GHz
      Noise Figure
      1.6 dB
      Datasheet
      Model
      ACLNBW-Ka Ultra-Wideband Series
      Frequency
      17.7 - 22.2 GHz
      Noise Figure
      1.8 dB
      Datasheet
      Model
      ACLNBW-Ka Ultra-Wideband Series Simultaneous Outputs
      Frequency
      17.7 - 22.2 GHz
      Noise Figure
      1.8 dB
      Datasheet

      LNAs

        Ka Band

        Model
        ACLNA-Ka Wideband
        Frequency
        17.7 - 20.2 GHz
        Noise Figure
        1.6 dB
        Datasheet
        Model
        ACLNA-Ka Wideband
        Frequency
        17.7 - 21.2 GHz
        Noise Figure
        1.6 dB
        Datasheet
        Model
        ACLNA-Ka Ultra-Wideband
        Frequency
        17.7 - 22.2 GHz
        Noise Figure
        1.8 dB
        Datasheet

        Redundancy

          Model
          ACRS-IDU-V1
          Configuration
          1:1 or 1:2
          Application
          Indoor controller needed for LNA redundancy plates
          Datasheet
          Model
          ACRS-Ka-ODU-11-V1
          Configuration
          1:1
          Application
          Outdoor LNA redundancy plate Ka-band
          Datasheet
          Model
          ACRS-Ka-ODU-12-V1
          Configuration
          1:2
          Application
          Outdoor LNA redundancy plate Ka-band
          Datasheet
          Model
          ACRS-ODU-11-V1
          Configuration
          1:1
          Application
          Outdoor controller for BUCs & LNBs
          Datasheet

          Freq. Converters

            Ka Band

            Model
            ACCVT-LKa-Ex-V1
            Frequency
            27.5 - 31.0 GHz
            Description
            Multiple band upconverter with LO integrated indoor applications
            Datasheet
            Model
            ACCVT-LKa-E28-V4
            Frequency
            27.5 - 30.0 GHz
            Description
            Dual band series upconverter simultaneous inputs
            Datasheet
            Model
            ACCVR-KaL-E29-V3
            Frequency
            27.0 - 29.5 GHz
            Description
            Dual band series downconverter simultaneous outputs
            Datasheet
            Model
            ACCVR-KaL-E28-V4
            Frequency
            27.5 - 30.0 GHz
            Description
            Dual band series downconverter simultaneous outputs
            Datasheet

            X Band

            Model
            ACCVT-LX-E1-V31
            Frequency
            7.9 - 8.4 GHz
            Description
            Upconverter from L-band to X-band 1/3 rackmount
            Datasheet
            Model
            ACCVR-XL-E1-V31
            Frequency
            7.25 - 7.75 GHz
            Description
            Downconverter from X-band to L-band 1/3 rackmount
            Datasheet
            Model
            ACRC-V31
            Frequency
            N/A
            Description
            Rack frame 1 UA and 3 modules capacity
            Datasheet
            Model
            ACRC-V62
            Frequency
            N/A
            Description
            Rack frame 2 UA and 6 modules capacity
            Datasheet

            Transceivers

              X Band

              Model
              ACMTR-X Medium Power Series
              Frequency
              RX: 7.25 - 7.75 GHz, TX: 7.9 - 8.4 GHz
              Power (P1dB)
              100 W
              Datasheet
              Model
              ACTR-X High Power Series
              Frequency
              RX: 7.25 - 7.75 GHz, TX: 7.9 - 8.4 GHz
              Power (P1dB)
              200 W
              Datasheet

              TLTs

                Model
                ACTLT-C-E1-V2
                Input Frequency
                5.850 - 6.725 GHz
                Output Frequency
                3.4 - 4.2 GHz
                Datasheet
                Model
                ACTLT-X-E1-V31 (1/3 rackmount family)
                Input Frequency
                7.9 - 8.4 GHz
                Output Frequency
                7.25 - 7.75 GHz
                Datasheet
                Model
                ACTLT-Ku-E1-V2
                Input Frequency
                13.75 - 14.5 GHz
                Output Frequency
                10.7 - 12.75 GHz
                Datasheet
                Model
                ACTLT-DBS-E1-V1
                Input Frequency
                17.3 - 18.1 GHz
                Output Frequency
                10.95 - 11.75 GHz
                Datasheet

                GNSS/INS

                  Model
                  Dragonfly
                  Description
                  Attitude determination and navigation system, 4 GNSS Rx, with and without RTK
                  Datasheet
                  Model
                  Firefly
                  Description
                  Attitude determination and navigation system, 2 GNSS Rx, with and without RTK
                  Datasheet
                  Model
                  Planthopper
                  Description
                  Attitude determination and navigation system, 1 GNSS Rx, with and without RTK
                  Datasheet
                  Model
                  ACGNS-L1_E1-FE-V2
                  Description
                  GNSS GPS L1 / Galileo E1 USB advanced Front End
                  Datasheet
                  Model
                  ACGNS-L5_E5a-FE
                  Description
                  GNSS GPS L5 / Galileo E5a Radio Front-End
                  Datasheet
                  Model
                  ACGNS-L1_E1-FE
                  Description
                  GNSS GPS L1 / Galileo E1 Radio Front-End
                  Datasheet
